120W Mono Solar Panel Perfect Size for Caravan, RV and 4WD | Harvok Power
120W Mono Solar Panel Perfect Size for Caravan, RV and 4WD | Harvok Power
Harvok Power selected for better power regeneration and storage
Key Specs
- IP67 Water Proof Junction Box
- Snow Load Capacity 36Kg per Square Meter
- Hail Impact Resistant 21mm in diameter
- Extreme Working Temperature -40 up to +85 C
- 22.8% Efficiency above the average market benchmark
- 10 Year performance guarantee at 80% output.
|
Nominal Power(Pmax)
|
120W |
| Open circuit Voltage(Voc) | 28.8V |
| Short circuit current(Isc) | 5.18A |
| Voltage at Nominal Power(Vmp) | 26 |
| Circuit at Nominal Power(Imp) | 4.89A |
| Module Efficiency (%) | 22.8% |
|
Operating Temperature
|
-40 to +85 C |
| Maximum System Voltage |
1000VDC (IEC) /600VDC (UL)
|
| Fire Resistance Rating |
Type 1(in accordance with 1703 ) / CIass C (IEC61730)
|
| Maximum Series Fuse Rating |
20A
|
| Front cover |
3.2mm,Anti-Reflection Coating.Tempered Glass
|
| Frame |
Anodized Aluminium Alloy
|
| Junction Box |
IP 67 Rated
|
| Cable |
TOV 1x2.5mm2
|
| Connector |
PV Connector(compatible)
|
| Model | 120W |
|
Cells Size
|
166x83mm
|
| Number Of Cells |
4x10
|
| Dimension |
705x885x25mm
|
| Weight |
6.8kg
|
